◉   Business Challenges

What are the potential quality hazards of IC SMT process?

How is the reliability of SMT process verified？

◉   Service Content

Ⅰ. Applicable Test Standards

J-STD-004B Requirements for Soldering Fluxes

J-STD-005 Requirements for Soldering Pastes

J-STD-006 Requirements for Electronic Grade Solder Alloys and Fluxed and Non-Fluxed Solid Solders for Electronic Soldering Applications

JIS Z 3197 Testing methods for soldering fluxes

JIS Z 3283 Resin flux cored solders

ASTM D1298 Standard Test Method for Density,Relative Density,or API Gravity of Crude Petroleum and Liquid Petroleum Products by Hydrometer Method

GB/T 507 Insulating liquids. Determination of the breakdown voltage at power frequency

GB/T 6324.2 Test method of organic chemical products. Part 2:Determination of dry residue after evaporation on a water bath for volatile organic liquids

GB/T 9491 Liquid flux for soldering(Rosin base)

GB/T 9740 Chemical reagent. General method for the determination of dry residue after evaporation

GB/T 12582 Liquid hydrocarbons. Determination of electrical conductivity. Precision meter

IPC TM-650 Test Methods Manual, etc.

Ⅱ. Product Range

Electronic and electrical products, Solder paste, Solder, Solder wire, Flux, Cleaning agent, etc.
Ⅲ. Standard Sample Requirements

Please contact our business or customer service, based on specific standards.

Ⅳ. Test Item

◉   CTI Solution

CTI provides a comprehensive one-stop solution of reliability testing, including:

Environmental test

Reliability test

Reliability design

Reliability analysis

Product evaluation

Reliability training and consulting

◉   Our Strengths

CTI has many advanced equipments and has passed CMA/CNAS qualification accreditation, the test data is accurate and reliable, and the test report has international credibility.

The scientific laboratory information management system ensures the efficient operation of each service link.

The technical expert team has rich practical experience and can provide professional, rapid and comprehensive one-stop service.

The service network is all over the world, and many first-line brands designate cooperative laboratories.

◉ Service Process

Consult customer service → confirm the test plan → fill in the application form → send the sample → pay the test fee → test → send electronic report → express paper report

◉ Frequently Asked Question

How long does the test period take？

The normal period is 5-7 working days (except the time when the sample is in the test chamber). If you need urgent help, please contact our sales or customer service.

How much sample is needed for SIR （surface insulation resistance） and ECM （electrochemical migration）test of flux?

It is each recommended to send 200ml flux for SIR or ECM test.

what is the channel definition in ECM test?

In the process of ECM testing or SIR testing, To determine the number of test channels is to determine the number of positions of insulation resistance monitoring.

How long is the corrosion test exposure period of solder paste?

Different standards provide different test time. For example, GB/T 9491 recommends 7 or 14 days, while IPC J-STD-004B recommends 10 days, so the test time should be based on the standard specified by the customer.

How much solder paste sample is needed to test the wettability test?

It is recommended to send samples for more than 400g. If other test items need to be tested at the same time, it is advised to send more samples for standby use.
